UKC1 E Bike Full Colour LCD Display 36V 48V 52V 60V 72V Mode Sinewave Squarewave

🖥️ Full Colour E-Bike Display (2021 Release)

🚴 Upgrade your ride with the newest 3.5-inch IPS full-colour display, designed for clarity, style, and performance.

⚡ Key Features

• 📱 Screen Size: — 3.5-inch IPS Display
• 🔋 Battery Supply: — 24V / 36V / 48V / 52V / 60V / 72V compatible
• ⚡ Rated Operating Power: — 1W
• 🚀 Max Operating Power: — 5W
• 🔌 USB Charging Port: — 5V / 500mA (charge your devices on the go!)
• 🔄 Controller Support Current: — 100mA
• 🌊 Waterproof Grade: — IP65 – built to handle the elements
• 🌡️ Operating Temp: — -20°C ~ 70°C
• 📦 Storage Temp: — -30°C ~ 80°C
• 🎛️ Size: — 111.1 × 66.8 × 82.8 mm
• 🔊 Sine Wave Controller Compatible
• 🚫 Not compatible with Sabvaton (OMD system)

🔒 Reliability

• ⚡ Ultra-low leakage current: <1uA (saves battery when off)
  ✅ Rugged & reliable for all-weather riding

⚠️ Important Compatibility Notice

• 📡 There are two protocol types for this display.
  ✅ Our display uses the OMD system – fully compatible with all our kits & accessories.
  ❓ Unsure it will work with your controller? 👉 Please send us a picture of your controller’s serial number, and we’ll confirm compatibility.
  📞 Need help? Contact us anytime – we’ll be happy to assist!

📞 Compatibility Help

• Not sure if it will work with your setup? 👉 Contact us anytime – our team will make sure you get the right display for your e-bike!

🚚 Shipping & Returns

• 📦 Orders dispatched within 24 hours (Mon–Fri) if ordered before 1PM
• 🚛 Carriers: Royal Mail, DPD or FedEx (Tracked)
• ⏱️ Estimated delivery: 1–2 working days
• ↩️ 30-day FREE returns – Buyer pays postage – Item must be returned in new condition

🤝 Need Help?

• We aim to respond to all messages within 24 hours Monday–Friday 9am – 6pm and some weekends. Our team is always friendly & customer-focused, here to help with your e-bike build. 💬
